Starter for Forklifts

Starter for Forklift - Today's starter motor is typically a permanent-magnet composition or a series-parallel wound direct current electrical motor with a starter solenoid installed on it. When current from the starting battery is applied to the solenoid, mainly via a key-operated switch, the solenoid engages a lever that pushes out the drive pinion which is positioned on the driveshaft and meshes the pinion utilizing the starter ring gear which is found on the engine flywheel.

When the starter motor begins to turn, the solenoid closes the high-current contacts. As soon as the engine has started, the solenoid has a key operated switch which opens the spring assembly to be able to pull the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by an overrunning clutch. This permits the pinion to transmit drive in only a single direction. Drive is transmitted in this way through the pinion to the flywheel ring gear. The pinion continuous to be engaged, like for instance because the driver did not release the key once the engine starts or if there is a short and the solenoid remains engaged. This causes the pinion to spin independently of its driveshaft.

This aforementioned action stops the engine from driving the starter. This is an important step because this particular type of back drive would allow the starter to spin really fast that it could fly apart. Unless modifications were done, the sprag clutch arrangement would prevent utilizing the starter as a generator if it was employed in the hybrid scheme discussed earlier. Normally an average starter motor is intended for intermittent utilization which would prevent it being used as a generator.

Therefore, the electrical parts are designed to be able to work for roughly under thirty seconds to be able to avoid overheating. The overheating results from very slow dissipation of heat because of ohmic losses. The electrical parts are meant to save weight and cost. This is the reason the majority of owner's instruction manuals intended for vehicles suggest the driver to stop for at least 10 seconds after each and every 10 or 15 seconds of cranking the engine, whenever trying to start an engine which does not turn over at once.

The overrunning-clutch pinion was introduced onto the marked in the early part of the 1960's. Previous to the 1960's, a Bendix drive was used. This particular drive system functions on a helically cut driveshaft which has a starter drive pinion placed on it. Once the starter motor begins turning, the inertia of the drive pinion assembly enables it to ride forward on the helix, hence engaging with the ring gear. When the engine starts, the backdrive caused from the ring gear enables the pinion to surpass the rotating speed of the starter. At this point, the drive pinion is forced back down the helical shaft and therefore out of mesh with the ring gear.

The development of Bendix drive was made during the 1930's with the overrunning-clutch design known as the Bendix Folo-Thru drive, developed and launched during the 1960s. The Folo-Thru drive consists of a latching mechanism along with a set of flyweights within the body of the drive unit. This was better for the reason that the typical Bendix drive used to disengage from the ring once the engine fired, even though it did not stay running.

When the starter motor is engaged and begins turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. When the drive unit is spun at a speed higher than what is achieved by the starter motor itself, for example it is backdriven by the running engine, and after that the flyweights pull outward in a radial manner. This releases the latch and allows the overdriven drive unit to become spun out of engagement, therefore unwanted starter disengagement can be prevented before a successful engine start.
