Pinion for Forklifts

Pinion for Forklift - The main axis, called the king pin, is seen in the steering machinery of a forklift. The very first design was a steel pin wherein the movable steerable wheel was mounted to the suspension. For the reason that it could freely turn on a single axis, it limited the levels of freedom of movement of the rest of the front suspension. In the nineteen fifties, the time its bearings were replaced by ball joints, more detailed suspension designs became obtainable to designers. King pin suspensions are still utilized on some heavy trucks because they have the advantage of being capable of carrying much heavier weights.

Newer designs no longer limit this particular machine to moving like a pin and today, the term may not be used for a real pin but for the axis in the vicinity of which the steered wheels turn.

The KPI or also known as kingpin inclination may also be referred to as the SAI or steering axis inclination. These terms define the kingpin when it is positioned at an angle relative to the true vertical line as viewed from the back or front of the lift truck. This has a major impact on the steering, making it tend to go back to the centre or straight ahead position. The centre position is where the wheel is at its peak position relative to the suspended body of the lift truck. The vehicles' weight tends to turn the king pin to this position.

One more effect of the kingpin inclination is to arrange the scrub radius of the steered wheel. The scrub radius is the offset amid the projected axis of the steering down through the kingpin and the tire's contact point with the road surface. If these points coincide, the scrub radius is defined as zero. Although a zero scrub radius is possible without an inclined king pin, it requires a deeply dished wheel so as to maintain that the king pin is at the centerline of the wheel. It is much more sensible to slant the king pin and use a less dished wheel. This also provides the self-centering effect.

Click to Download the pdf
